The Exile Lightsaber

***NO SOUND (STUNT SABER) SETUP***
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included), or 4 x AAA Battery Setup [Depends on compatibility with the selected hilt]
- Silver Finish Non-Illuminated AV Switch
- No Sound Effects
- 36" Heavy Duty Blade with Round Tip


***PREMIUM SOUND SETUP***
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- Obsidian Lite Soundboard installed
- 36” Heavy Duty Blade with Round Tip


***ULTRAPROFFIE SOUND SETUP***
Read about UltraProffie here (link will open in a new tab)
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- UltraProffie Zero Soundboard installed
- 36” Heavy Duty Blade with Round Tip


***NEOPIXEL BLADE SOUND SETUP***
Read about UltraProffie here (link will open in a new tab)
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- UltraProffie Lite Soundboard installed
- 36” NeoPixel Blade Included

***NOT INCLUDED***
-Blade Plug
-Covertec Clip
-Lightsaber Stand
-Blade Retention Wrench
-USB Cable
-Recharge Port
-Flash on Clash

Pick the type of sound install you want for your saber.

Obsidian Lite Sound with Chassis:

Overall
-Single sound font that is not reprogrammable (does not come with a USB port to connect your saber to a computer)
-Onboard menus for brightness and volume
-No smooth swing
-2Watt Speaker
Saber with Premium Sound
-Single blade color
-Flash on Clash optional (will still make the clash sounds)
Neopixel Saber with Sound
-Color changing through onboard menu
-Flash on Clash built in

Obsidian USB V3 Sound with Chassis:

Overall
-Single sound font that is reprogrammable (comes with a USB port to connect your saber to a computer with the Obsidian Launcher)
-Onboard menus for brightness and volume
-No smooth swing
-2Watt Speaker
Saber with Premium Sound
-Single blade color
-Flash on Clash optional (will still make the clash sounds)
Neopixel Saber with Sound
-Color changing through onboard menu
-Flash on Clash built in

Obsidian USB V4 Sound with Chassis:

Overall
-Multiple built in sound fonts that are reprogrammable (comes with a USB port to connect your saber to a computer with the Obsidian Launcher)
-Onboard menus for sound font, brightness, and volume
-No smooth swing
-2Watt Speaker
Saber with Premium Sound
-Single blade color
-Flash on Clash optional (will still make the clash sounds)
Neopixel Saber with Sound
-Color changing through onboard menu
-Flash on Clash built in

UltraProffie Zero:

Overall
-Single sound font that is only reprogrammable through the use of a DevPort Tool (only for advanced proffie users. Use of the DevPort Tool is not covered under warranty)
-Smooth swing
-Wall melt
-Tip Drag
-Blaster Mode
-Onboard menus for Brightness, Volume, Smooth swing sensitivity, and blade style preset
-USB port on the soundboard that allows you to charge the battery without removing it from the chassis
-3Watt Speaker
Saber with Premium Sound
-Single blade color
-Flash on Clash optional (will still make the clash sounds)
-6 built in blade style presets (Solid, Shimmer, Fast Pulse, Audio Shimmer, Real Pulse, and Morph)
Neopixel Saber with Sound
-Color changing through onboard menu
-Flash on Clash built in
-25 built in blade style presets

UltraProffie Lite:

Overall
-25 built in sound fonts that are reprogrammable with the MicroSD card that is removable from the soundboard
-Smooth swing
-Wall melt
-Tip drag
-Blaster Mode
-Onboard menus for color changing, sound font/blade style preset, brightness, volume, and smooth swing sensitivity
-USB port on the soundboard that allows you to charge the battery without removing it from the chassis
-Flash on Clash built in
-3Watt Speaker
Saber with Premium Sound
-25 built in blade styles
Neopixel Saber with Sound
-25 built in blade styles

Basic Sound

Overall
-9 built in sound fonts that are not reprogrammable
-USB port that allows you to charge the battery without removing it from the chassis
-Onboard menus for color changing, volume, sound fonts, background track
-Blaster deflect
1Watt Speaker
Saber with Basic Sound
-3 built in blade styles (Steady, Unstable, Pulse)
Neopixel Saber with Sound
-8 built in blade ignition styles (Standard, Unsteady, Block, Stack, Merge, Phaser, Swift, and Storm)
-14 built in blade styles (Steady, Pulse, Rainbow, Candy Blade, Unsteady, Lightning, Morph 1, Raindrop, Morph 2, Flicker, Pattern 1, Pattern 2, Rainbow Morph, Strobe)

Choose the color of your blade!

Blazing Red, Consular Green, Guardian Blue, Fire Orange, and Adegan Silver are all made with single diode High Powered LEDs.

Violet Amethyst, Sun Rider's Destiny, Arctic Blue, Bane's Heart, Blue Violet Amethyst, Pyrestone Orange, and Sentinel Yellow are all made with multicolor RGB LEDs and combining multiple diodes to create the Blade Color.

Tri Blazing Red, Tri Consular Green, Tri Guardian Blue, Tri Fire Orange, Tri Arctic Blue and Tri Adegan Silver are all made using Tri Cree LEDs with all three diodes wired together. [Not compatible with Flash on Clash]

To use color discs you remove the blade, drop a disc down the blade socket, then replace the blade. These only work properly with the Adegan Silver blade color. Colors obtained using color discs create a blade that is significantly dimmer than if you just ordered that color blade standalone (for example Guardian Blue is much brighter than using a blue color disc).

Ultrasabers NeoPixel blades are capable of adjusting to any color you can imagine, and will arrive preset with a variety of colors!

PLEASE NOTE: Flash on Clash is not possible with Tri Cree LEDs. If you have selected a Tri-Cree LED, then your saber cannot support Flash on Clash. You can only have one or the other. If you would like to add Flash on Clash, please go back and select a non-Tri-Cree LED blade color.

***The VC2 Charger is HIGHLY recommended for all Li-Ion setups. This is by far the superior charger for Li-Ion battery care and maintenance.***

Standard Setup is a setup that uses regular AAA batteries to power your saber. (4xAAA batteries for all colors). You can use regular Alkaline batteries or rechargeable NiMh batteries (not provided).

Our Li-Ion battery Setups are the superior battery pack configurations. A Li-Ion battery configuration is required for all sabers with sound. (Your saber only comes with sound if it says WITH SOUND in the title of the setup name)

Check out our FAQ and video on Recharge Ports here! (Link will open in a new tab)

We offer three different Recharge Port Charger options depending on your battery setup. If you plan on opting out of a charger to use one you already own, please read our FAQ to ensure that your charger is compatible and avoid damaging your electronics.

Recharge Ports are not compatible with our Basic Soundboard.

Select what length of blade you want.

Check out our SaberForum post that explains the difference between each of our available blade types here! (Link will open in a new tab)

Select what type of blade you want to come with your UltraSaber.

> Mid-Grade
Mid-Grade blades are an excellent all around choice. They are lightweight and allow the true color of the LED through at maximum brightness. These blades are durable enough for light sparring, but are not as thick as our Heavy Grade blades and are therefore not recommended for full contact/ heavy dueling.

> UltraEdge
UltraEdge blades are available in the above Mid & Heavy grades, and are created from a white polycarbonate tube providing a thick, bright blade. The white polycarbonate creates a FULLER blade look but isn't as bright as non-Ultraedge blades.

> Heavy Grade & Ultra Edge Heavy Grade
Our Heavy Grade blades weigh literally twice as much as the Mid-Grade blades, and they do trade off a bit of brightness in exchange for their brutal strength. These blades are recommended blade for those who intend on full contact dueling or sparring against wooden Bokken or similar weaponry.

For more detailed information, check out our SaberForum post that explains the difference between each of our available lightsaber blade types here. (Link will open in a new tab)

Our NEW Basic Soundboard comes preloaded with 9 sound fonts. An onboard menu allows you to change between the different sound fonts, as well as change your blade color to any color on the spectrum.

Select your lightsaber's A/V Switch.  The AV Switch will control the power to the saber as well as allow you to operate the Obsidian Soundboard, UltraProffie, NeoPixel, or Diamond Controller if your saber is configured to include them.

Select from the standard Guarded switch, an illuminated or non-illuminated AV Switch switch here. These AV switches are just for cosmetic purposes- they make your saber look cool, they do not serve for any additional functionality, and are not required for any additional functionality over the guarded switch.

Choose the switch hole type for your empty hilt!

Guarded Switch Hole Type: Your empty hilt will have a switch hole drilled to work with our normal guarded switches. These switches are meant to be PRESS FIT into the switch hole. No backing nut or adhesive required.

AV Switch Hole Type: Your empty hilt will have a switch hole ENLARGED to work with our 16mm AV switches. These switches are meant to be attached with a backing nut and/or High Performance hot melt adhesive.

Round Tips look round and pointed tips look pointed. There is absolutely no other difference.

There is a surcharge for pointed tips because we do not stock these and would have to custom make the blade for you. They are not superior in any way. It is just a preference if you want your tip to be round or pointed.

99% of Ultrasaber blades are made with round tips.

The Blade Retention Screw Wrench is just the small allen wrench required to remove the blade. This wrench is NOT required to hold the blade in place. That screw is provided standard with every Ultrasaber.

You can also purchase these separately from any hardware store, or you may already own a set of these. Purchasing this one guarantees that you will get the correct size wrench for the screw in your Ultrasaber. Using the wrong size wrench can strip your retention screw.

All Ultrasaber retention screws require Standard size hex wrenches, DO NOT USE METRIC SIZE WRENCHES, you will strip the screw.

Blade Plugs are designed to be inserted in your saber when the blade is removed to protect your LEDs. They give the hilt a cool look when the saber is ignited, and prevent you from shining a high powered LED directly into yours or someone else's eyes.

Select an option above to see illuminated examples of each blade plug.

Day blades are a fantastic solution to keep your saber looking perfect during long days of brightly lit conventions, outdoor events, intense studio lighting, or times when you don't have your saber powered on.

Day Blades are 36" Heavy Grade blades, with a 1" diameter.

Please Note: A Day Blade's colored Polycarbonate will affect the appearance of the color of your saber's LED when it is ignited. Please make sure to select a Day Blade blade that best matches your saber's blade color!

Very basic assembly is required for stands. Any damage from assembling incorrectly is not covered under warranty.

***Sabers in pictures are NOT included with the stand, and are only shown for reference***

A MICRO USB cable is needed in order to interface your saber's Diamond Controller with the Ultrasabers Launcher on your computer when changing your installed fonts, effects, and gestures.

You can download the Ultrasabers Launcher for the Diamond Controller here.

[Note: This cable is NOT used for any charging purposes]

A MINI USB cable is needed in order to interface your saber's Obsidian Soundboard or Emerald Driver with the Obsidian Launcher on your computer when changing your installed soundfonts or blade color.

You can download the Obsidian Launcher here.

[Note: This cable is NOT used for any charging purposes]

The DevPort can only be used with UltraProffie soundboards. It has no compatibility with Obsidian, Emerald, or Diamond boards. The DevPort is required to connect any UltraProffie board to www.ultraproffie.com (requires Google Chrome) or Arduino via USB.

Any use of the DevPort with the UltraProffie soundboard is not covered under warranty. This tool allows you to makes changes to the actual coding of the soundboard and is for advanced users only.

A belt clip wheel is the knob on a lightsaber that allows you to attach the lightsaber to a belt clip and wear it on your belt.

A clip is the clip that you wear on your belt that allows you to hang your lightsabers from a belt clip wheel for costuming or to just carry your saber in general.  This is typically done with the blade removed.  The blades are removable on ALL Ultrasabers.

Not all Ultra Sabers come standard with a belt clip wheel. All Prophecy models, all Shock Models, The Bane, The Bellicose, The Overlord, The Guardian, The Graflex SE & CE, and The Consular are just a few of the sabers that come standard with a belt clip wheel and one does not have to be added or purchased.


You can purchase a belt clip wheel separately from here.
(Link will open in a new tab)

You can purchase a belt clip clip separately from here.
(Link will open in a new tab)

A belt clip wheel is the knob on a lightsaber that allows you to attach the lightsaber to a covertec clip and wear it on your belt.

If your UltraSaber doesn't come standard with a belt clip wheel, you can have one added before it ships. In the comments field of your order, specify where on the hilt and what color covertec wheel (silver, black, or gold) and we'll take care of that for you before the saber ships.

Please keep instruction to TWO things ONLY in the comments field of the order at checkout:

1: Left, Right, or Rear (activation switch representing the front) and
2. Near Pommel or Above Switch.

Those are the only two pieces of information we need for belt clip wheel location requests. Please do not use degrees or clock rotations or include image links for belt clip wheel location requests. A proper belt clip wheel location request would be "Left Side Near Pommel" or "Rear Side Above Switch" or "Rear Side Near Pommel" etc. You can also not put anything in the comments field and we will select an excellent default location for your belt clip wheel install.
