Renegade Lightsaber

***NO SOUND (STUNT SABER) SETUP***
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included), or 4 x AAA Battery Setup [Depends on compatibility with the selected hilt]
- Silver Finish Non-Illuminated AV Switch
- No Sound Effects
- 36" Heavy Duty Blade with Round Tip


***PREMIUM SOUND SETUP***
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- Obsidian Lite Soundboard installed
- 36” Heavy Duty Blade with Round Tip


***ULTRAPROFFIE SOUND SETUP***
Read about UltraProffie here (link will open in a new tab)
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- UltraProffie Zero Soundboard installed
- 36” Heavy Duty Blade with Round Tip


***NEOPIXEL BLADE SOUND SETUP***
Read about UltraProffie here (link will open in a new tab)
- 18650 Li-Ion Setup Battery Configuration (Charger & Battery included)
- Silver Finish Non-Illuminated AV Switch
- UltraProffie Lite Soundboard installed
- 36” NeoPixel Blade Included

***NOT INCLUDED***
-Blade Plug
-Covertec Clip
-Lightsaber Stand
-Blade Retention Wrench
-USB Cable
-Recharge Port
-Flash on Clash

Pick the type of sound install you want for your saber.

Features of the UltraProffie Soundboard:

Check out our FAQ for a description of the differences between UltraProffie Lite and UltraProffie Zero.

The UltraProffie board features a simple to use, single button and gesture-controlled on-board settings menu that allows you to adjust blade brightness, color with select options, sound with select options, sensitivity, volume, and more straight from the saber.
-Up to 25 preloaded sound + blade style presets.
-Smooth swing built in to every UltraProffie Soundboard.
-Tip drag, all-new ignition & deactivation effects, new lockup, blaster block, wall melt, blaster mode, force lightning and so so so much more- all baked right in when you get it with a Neopixel Blade.
-Advanced sensitivity controls for every single motion your saber is capable of.
-Switch your Ultrasaber into Stealth-Mode for ~1/3rd power output, to extend your saber’s battery life.
-Upgraded from a 2watt to a 3Watt speaker.
-Built in USB recharge port on each soundboard.
-Auto-power-off at timeout and low battery.
-So much more.



Visit the UltraProffie Launcher here for saber controls and open source documentation (Requires Google Chrome).
View and download the UltraProffie Lite Guide here.
View and download the UltraProffie Zero Guide here.

Features of the NEW Obsidian Soundboard with Chassis are:

-Built on chassis, ⏀1.3”, 4” long
-Powered by a single 3.7V, 18650 Li-Ion rechargeable battery
-Built-in battery holder and electrical protection
-Built-in audio amplifier and speaker
-Drives 2 LEDs and a 127-pixel string blade, simultaneously
-Up to 10 fonts, up to 25 sounds per font
-Up to 6 : 40 minutes audio memory
-Auto-power-off at timeout and low battery

Click here for technical specs for NEW Obsidian Soundboard.

Click here for users guide for NEW Obsidian Soundboard.

Features of the Basic Soundboard:

-Comes with 9 pre-installed soundfonts that can't be changed
-Comes standard with a recharge port on the chassis for convenient charging
-Uses a 1W speaker, while UltraProffie uses a 3W speaker

Ultrasabers NeoPixel blades are capable of adjusting to any color you can imagine, and will arrive preset with a variety of colors!

Choose the color of your main blade!

Blazing Red, Consular Green, Guardian Blue, Fire Orange, and Adegan Silver are all made with single diode High Powered LEDs.

Violet Amethyst, Sunrider's Destinty, and Arctic Blue are all made with multicolor RGB LEDs and combining two diodes to create the Blade Color.

To use color discs you remove the blade, drop a disc down the blade socket, then replace the blade. These only work properly with the Adegan Silver blade color. Colors obtained using color discs create a blade that is significantly dimmer than if you just ordered that color blade standalone (for example Guardian Blue is much brighter than using a blue color disc).

Choose the color of your left blade!

To use color discs you remove the blade, drop a disc down the blade socket, then replace the blade. These only work properly with the Adegan Silver blade color. Colors obtained using color discs create a blade that is significantly dimmer than if you just ordered that color blade standalone (for example Guardian Blue is much brighter than using a blue color disc).

Choose the color of your right blade!

To use color discs you remove the blade, drop a disc down the blade socket, then replace the blade. These only work properly with the Adegan Silver blade color. Colors obtained using color discs create a blade that is significantly dimmer than if you just ordered that color blade standalone (for example Guardian Blue is much brighter than using a blue color disc).

Select what blade type and length you want.

Clear is made from clear polycarbonate and with the Ultrafilm in it, it has the "silvery" look to it.

White is made from white polycarbonate and is traditionally known as an "Ultraedge" blade.

Select what blade type and length you want.

Clear is made from clear polycarbonate and with the Ultrafilm in it, it has the "silvery" look to it.

White is made from white polycarbonate and is traditionally known as an "Ultraedge" blade.

Check out our SaberForum post that explains the difference between each of our available blade types here! (Link will open in a new tab)

Select what blade type and length you want.

Clear is made from clear polycarbonate and with the Ultrafilm in it, it has the "silvery" look to it.

White is made from white polycarbonate and is traditionally known as an "Ultraedge" blade.

Check out our SaberForum post that explains the difference between each of our available blade types here! (Link will open in a new tab)

PLEASE NOTE: Flash on Clash is not possible with Tri Cree LEDs. If you have selected a Tri-Cree LED, then your saber cannot support Flash on Clash. You can only have one or the other. If you would like to add Flash on Clash, please go back and select a non-Tri-Cree LED blade color.

***The VC2 Charger is HIGHLY recommended for all Li-Ion setups. This is by far the superior charger for Li-Ion battery care and maintenance.***

Standard Setup is a setup that uses regular AAA batteries to power your saber. (4xAAA batteries for all colors). You can use regular Alkaline batteries or rechargeable NiMh batteries (not provided).

Our Li-Ion battery Setups are the superior battery pack configurations. A Li-Ion battery configuration is required for all sabers with sound. (Your saber only comes with sound if it says WITH SOUND in the title of the setup name)

Check out our FAQ and video on Recharge Ports here! (Link will open in a new tab)

We offer three different Recharge Port Charger options depending on your battery setup. If you plan on opting out of a charger to use one you already own, please read our FAQ to ensure that your charger is compatible and avoid damaging your electronics.

Recharge Ports are not compatible with our Basic Soundboard.

Select your lightsaber's A/V Switch.  The AV Switch will control the power to the saber as well as allow you to operate the Obsidian Soundboard, UltraProffie, NeoPixel, or Diamond Controller if your saber is configured to include them.

Select from the standard Guarded switch, an illuminated or non-illuminated AV Switch switch here. These AV switches are just for cosmetic purposes- they make your saber look cool, they do not serve for any additional functionality, and are not required for any additional functionality over the guarded switch.

Choose the switch hole type for your empty hilt!

Guarded Switch Hole Type: Your empty hilt will have a switch hole drilled to work with our normal guarded switches. These switches are meant to be PRESS FIT into the switch hole. No backing nut or adhesive required.

AV Switch Hole Type: Your empty hilt will have a switch hole ENLARGED to work with our 16mm AV switches. These switches are meant to be attached with a backing nut and/or High Performance hot melt adhesive.

Round Tips look round and pointed tips look pointed. There is absolutely no other difference.

There is a surcharge for pointed tips because we do not stock these and would have to custom make the blade for you. They are not superior in any way. It is just a preference if you want your tip to be round or pointed.

99% of Ultrasaber blades are made with round tips.

The claws of The Renegade can come with either a Black or Silver finish. Select the finish of your claws here.

The Renegade can come with a Large Style or Small Style Pommel. Select your pommel style here.

Large Pommel is pictured on the right and Small Pommel is pictured on the left.

(Renegade LE is shown for reference only, your hilt finish will match the hilt type ordered. See pictures of both pommel types in the item description below)

If you opt to ship assembled then the saber will come fully assembled right out the box. The claws will be attached and the blade will be attached and no assembly would be required for the hilt. You would just need to attach the blades. However, given the size of the saber fully assembled this will have to ship in a multiple boxes the shipping may cost more. Recommended for those that like instant gratification or do not like to to do any assembly.

If you opt to ship disassembled the saber will come with the claws removed and some (simple) assembly will be required. The claws will come detached and you will simply have to use a 3/32 hex wrench to attach them to the emitter. This will allow the saber to ship in our standard size box and will save some on shipping. Recommended for those that don't mind some assembly out the box.

The Blade Retention Screw Wrench is just the small allen wrench required to remove the blade. This wrench is NOT required to hold the blade in place. That screw is provided standard with every Ultrasaber.

You can also purchase these separately from any hardware store, or you may already own a set of these. Purchasing this one guarantees that you will get the correct size wrench for the screw in your Ultrasaber. Using the wrong size wrench can strip your retention screw.

All Ultrasaber retention screws require Standard size hex wrenches, DO NOT USE METRIC SIZE WRENCHES, you will strip the screw.

Blade Plugs are designed to be inserted in your saber when the blade is removed to protect your LEDs. They give the hilt a cool look when the saber is ignited, and prevent you from shining a high powered LED directly into yours or someone else's eyes.

Select an option above to see illuminated examples of each blade plug.

Day blades are a fantastic solution to keep your saber looking perfect during long days of brightly lit conventions, outdoor events, intense studio lighting, or times when you don't have your saber powered on.

Day Blades are 36" Heavy Grade blades, with a 1" diameter.

Please Note: A Day Blade's colored Polycarbonate will affect the appearance of the color of your saber's LED when it is ignited. Please make sure to select a Day Blade blade that best matches your saber's blade color!

Very basic assembly is required for stands. Any damage from assembling incorrectly is not covered under warranty.

***Sabers in pictures are NOT included with the stand, and are only shown for reference***

A MICRO USB cable is needed in order to interface your saber's Diamond Controller with the Ultrasabers Launcher on your computer when changing your installed fonts, effects, and gestures.

You can download the Ultrasabers Launcher for the Diamond Controller here.

[Note: This cable is NOT used for any charging purposes]

A MINI USB cable is needed in order to interface your saber's Obsidian Soundboard or Emerald Driver with the Obsidian Launcher on your computer when changing your installed soundfonts or blade color.

You can download the Obsidian Launcher here.

[Note: This cable is NOT used for any charging purposes]

The DevPort can only be used with UltraProffie soundboards. It has no compatibility with Obsidian, Emerald, or Diamond boards. The DevPort is required to connect any UltraProffie board to www.ultraproffie.com (requires Google Chrome) or Arduino via USB.

Any use of the DevPort with the UltraProffie soundboard is not covered under warranty. This tool allows you to makes changes to the actual coding of the soundboard and is for advanced users only.

A belt clip wheel is the knob on a lightsaber that allows you to attach the lightsaber to a belt clip and wear it on your belt.

A clip is the clip that you wear on your belt that allows you to hang your lightsabers from a belt clip wheel for costuming or to just carry your saber in general.  This is typically done with the blade removed.  The blades are removable on ALL Ultrasabers.

Not all Ultra Sabers come standard with a belt clip wheel. All Prophecy models, all Shock Models, The Bane, The Bellicose, The Overlord, The Guardian, The Graflex SE & CE, and The Consular are just a few of the sabers that come standard with a belt clip wheel and one does not have to be added or purchased.


You can purchase a belt clip wheel separately from here.
(Link will open in a new tab)

You can purchase a belt clip clip separately from here.
(Link will open in a new tab)

A belt clip wheel is the knob on a lightsaber that allows you to attach the lightsaber to a covertec clip and wear it on your belt.

If your UltraSaber doesn't come standard with a belt clip wheel, you can have one added before it ships. In the comments field of your order, specify where on the hilt and what color covertec wheel (silver, black, or gold) and we'll take care of that for you before the saber ships.

Please keep instruction to TWO things ONLY in the comments field of the order at checkout:

1: Left, Right, or Rear (activation switch representing the front) and
2. Near Pommel or Above Switch.

Those are the only two pieces of information we need for belt clip wheel location requests. Please do not use degrees or clock rotations or include image links for belt clip wheel location requests. A proper belt clip wheel location request would be "Left Side Near Pommel" or "Rear Side Above Switch" or "Rear Side Near Pommel" etc. You can also not put anything in the comments field and we will select an excellent default location for your belt clip wheel install.
